High-precision handheld leak detector Automobile radiator suction gun helium leak detection equipment
Contact Person : Tessa Huang
Phone Number : +86 18027403449
WhatsAPP : +8618027403449
| Minimum Order Quantity : | 1 Set | Price : | Negotiatable |
|---|---|---|---|
| Packaging Details : | Plywood | Delivery Time : | 90 Days |
| Payment Terms : | L/C, T/T | Supply Ability : | 10 Set per month |
| Place of Origin: | China | Brand Name: | HeJin |
|---|---|---|---|
| Certification: | Calibration Certificate(Cost Additional) | Model Number: | HJ111 |
|
Detail Information |
|||
| Size: | ≤2200mm*2500mm*2000mm | Weight: | 2000KG |
|---|---|---|---|
| Leak Alarm Rate: | 5E-5 Mbar.l/sec | Energy Consumption: | 15KW |
| Number Of Vacuum Chambers: | 1 (Detects 1 Product Each Time) | Helium Fill Pressure: | 0-0.5MPa |
| Gross Leak Detection Method: | Negative Pressure | Production Cycle Time: | 60 S/piece (including 6s For Manual Installation) |
| Highlight: | High Precision Leak Testing Equipment,High Precision Helium Leak Detection Chamber |
||
Product Description
Advanced 5E-5 mbar·l/sec Helium Leak Detection Chamber for High-Precision Leak Testing Equipment
In the field of leak testing, the Advanced 5E-5 mbar·l/sec Helium Leak Detection Chamber represents a significant breakthrough. It is specifically designed for high-precision leak testing, especially for the sealed welding of liquid injection holes in power batteries.
Product Operation and Function
This state-of-the-art equipment undertakes a series of meticulous processes. It starts with battery scanning and loading, followed by gross leak detection through the negative pressure method. Subsequently, evacuation and helium filling are carried out precisely. The core function lies in detecting the helium gas signals within the leak detection chamber. With its advanced technology, it can make high-precision, rapid, and accurate judgments regarding the leakage status of workpieces. Its full-flow architecture with true background and no zero suppression ensures the reliability and accuracy of the test results, making it capable of catering to the detection requirements of diverse products.
Key Product Parameters
| Parameter | Details |
| Size | ≤2200mm * 2500mm * 2000mm, providing a spacious yet manageable workspace for efficient testing operations. |
| Weight | 2000KG, indicating a sturdy and durable construction that can withstand continuous use. |
| Leak Alarm Rate | 5E-5 mbar·l/sec, demonstrating an extremely high level of sensitivity in detecting even the slightest leaks, crucial for applications where precision is of utmost importance. |
| Energy Consumption | 15KW, designed to balance performance and power efficiency for cost-effective operation. |
| Number of Vacuum Chambers | 1 (Detects 1 product each time), allowing for focused and detailed testing of individual items. |
| Helium Fill Pressure | 0 - 0.5MPa, offering flexibility in adjusting the helium pressure according to specific testing needs. |
| Gross Leak Detection Method | Negative Pressure, a proven and reliable technique for initial leak screening. |
| Production Cycle Time | 60s/piece (including 6s for manual installation), ensuring a relatively fast testing process without compromising accuracy. |
Product Image with Leak Testing Equipment:
Innovative R & D Capability: Our in-house developing and designing team is constantly striving for technological innovation. They are dedicated to creating products that not only meet but exceed industry standards. Customers can rely on us to provide unique and customized solutions based on their specific requirements.
Skilled Workforce: All our employees are highly experienced and proficient in their respective fields. From the technical team to the after-sales service staff, they ensure that every aspect of the product's lifecycle is handled with expertise and care.
Global After-Sales Service: We have a well-established global service network. Our working and sales teams are committed to providing prompt and efficient after-sales support, regardless of where the product is located. This ensures that customers can operate the equipment smoothly and resolve any issues quickly.
In conclusion, the Advanced 5E-5 mbar·l/sec Helium Leak Detection Chamber offered by Guangzhou Hejin Automation Control Technology Co., Ltd. combines outstanding technical specifications with the advantages of our company's service and innovation. It is undoubtedly the top choice for those seeking high-precision leak testing solutions.
