High Recovery Rate Helium Leak Detection System In Automatic Test Cycle With Leak Testing Apparatus

Product Description

 High Recovery Rate Helium Leak Detection System in Automatic Test Cycle with Leak Testing Apparatus

Product Overview

Detection Principle: This system is based on the basic principle of helium leak detection. Helium is used as a tracer gas to be filled into the workpiece, and then the leakage accuracy of the workpiece can be quickly and accurately determined by the helium leak detector.

Application Range: It is suitable for workpiece leak detection in various industries such as automotive, refrigeration, power generation, household appliances, electronics, pharmaceuticals, plumbing systems, and military fields.

Installation Requirements

Personnel Qualification: Installation must be carried out by trained professional installers.

Site Conditions

Power Supply: Three-phase five-wire 380VAC, power 15KW, equipped with 8 air switches. The height of the switches above the ground is ≥1.5M, and the distance from the main equipment placement position is ≤2M.

Gas Supply

At least 1 bottle of bottled helium (40 liters, 12MPa) with a 0.1MPa pressure reducing valve.

Bottled high-purity nitrogen (≥99.999%) with a 0.2MPa pressure reducing valve.

Clean compressed air with a pressure of 0.55 - 0.7MPa; the distance between the gas supply interface and the equipment placement position is ≤1M.

Other Facilities: Prepare an outdoor exhaust pipe with a diameter ≥3/4″, and the distance between the interface and the equipment placement position is ≤1M.

Product Image with Leak Testing Equipment:

Company Service Advantages

R&D and Design: The company has its own R&D and design team, which can provide customers with technologically innovative products and customize unique designs according to customers' ideas.

Technical Support: All employees are experienced and skilled.

After-sales Service: The working team and sales team can provide fast and efficient after-sales service for products sold globally.

Company Profile
Guangzhou Hejin Automation Control Technology Co., Ltd. is a modern enterprise specializing in the research and development, manufacturing, and sales of technology-intensive industrial equipment. Its leading products include vacuum helium leak detection equipment, automatic brazing machines for gas/liquid filling and recovery systems, lean production lines, and laboratory testing equipment. Under the guidance of Mr. Li Jianhe, an expert in vacuum and automated testing technologies, the company has proprietary core technologies and a large number of invention and utility patents. It adopts a new production model centered on development, design, assembly, debugging, and comprehensive after-sales support. The products meet the specific usage scenarios and technical specifications of customers. The products not only meet the domestic market but also are exported to countries and regions such as America, Europe, Asia, and Africa.
