Automobile High And Low Temperature Chamber Formula Constant Wet / Humidity
Contact Person : Tessa Huang
Phone Number : +86 18027403449
WhatsAPP : +8618027403449
| Minimum Order Quantity : | 1 set | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Plywood | Delivery Time : | 40 days |
| Payment Terms : | L/C, T/T | Supply Ability : | 10 set /month |
| Place of Origin: | China | Brand Name: | HeJin |
|---|---|---|---|
| Certification: | Calibration Certificate(cost additional) | Model Number: | AM0052 |
|
Detail Information |
|||
| Test Mode: | Positive Pressure Volume | Detection Speed: | Five Seconds |
|---|---|---|---|
| Pressure Limit: | 0KPa~100KPa | Sensor Accuracy: | 0.02%FS |
| Indication Error: | 0.001KPa | Admission Pressure: | 0.4MPa-0.8MPa |
| Equipment Power: | 1.0KW | Display Interface: | 10-inch Touch Screen |
| Highlight: | 0.4MPa Air Tightness Testing Equipment,Rearview Mirror Air Tightness Testing Equipment |
||
Product Description
Air tightness testing equipment for electric heating rearview mirror of automobile Auto Parts Test Equipment 0.4MPa-0.8MPa
Feature:
The shell is made of domestic high-quality steel plate, painted with paint, beautiful and durable.
The product has a built-in high-precision sensor, and the test accuracy can reach 0.02%FS.
6 Language support from the six countries to meet the needs of different use groups.
The 4. 10-inch color touch screen serves as a human-computer interaction interface, and the materialized icon is more intuitive and easy to understand.Auto Parts Test Equipment
Non-bridge valve island sealing technology, very small internal volume, to ensure the stability of the test.
Use a four-level pressure regulating device to completely exclude the impact of external pressure fluctuations on the test results.
Built-in multiple sets of serial ports, Ethernet ports, and PLC I / O interfaces can control the peripheral treatment devices or equipment, with simple programming.
Strong scalability can configure input and output equipment, such as: barcode scanner and printer and other data real-time storage to achieve product traceability, the historical record can be infinitely expanded (purchase).Auto Parts Test Equipment
Powerful upper computer software can realize network management and monitor operation status.
Simple operation, pressure debugging, pressure calibration, program selection, tooling control is easy to learn and easy to understand.
The system has up to 99 subprograms, which can set separate parameters for each one, which can be combined to achieve a complex test process.
The leakage tester has 8-switch input and 8-switch relay output for users.The user can enable the input and output ports to achieve the desired action by performing simple programming on the touch screen.And control the peripheral clamps.
All testing methods do not destroy the appearance and structure of the products to be tested, and realize non-destructive testing.
Parameters:
| Model | AM0052 Auto Parts Test Equipment |
| Test mode | Positive pressure volume |
| Control box size | Approximately length 300 * inlet depth 355 * height 335mm |
| Auxiliary tooling | Auxiliary tooling can be added for automation |
| Display interface | 10-inch touch screen |
| Multichannel | One, two, four channels |
| Detection speed | Five seconds |
| Login permissions management | Operator, technician, engineer, administrator level 4 authority |
| Multi-country language | Six-country languages (Chinese, English, Japanese, German, French, Russian) |
| Pressure limit | 0KPa~100KPa |
| Sensor accuracy | 0.02%FS |
| Indication error | 0.001KPa |
| Data Export | U disk export |
| Admission pressure | 0.4MPa-0.8MPa |
| Equipment power supply | 24V; Equipped with a 220V to 24V power supply Auto Parts Test Equipment |
| Equipment power | 1.0KW |
| Safety protection function | Overpressure protection, power supply low voltage protection, tooling grating protection |
